DiagWiki

Explaining Code with Interactive Diagrams, no api calls, no privacy concerns!

DiagWiki analyzes your code and generates diagram-based wiki pages that explain how your system works. Instead of reading walls of text, you explore interactive diagrams where you can click on any component to understand its role.

It is a local deployment tool that leverages large language models (LLMs) running on your machine via Ollama, ensuring your code never leaves your environment. So, no expensive API calls or data privacy concerns!

Click the image below to watch the demo video:

What It Solves

1. Understand complex codebase and present architecture visually with query chat boxes for clarity
2. Generate accurate, detailed diagrams automatically from code for documentation
3. Enable complete control of any step of the diagram generation process - either fully automatic or use instruction & designated files to guide the process.

Use DiagWiki to visualize this project itself

API Call Workflow for Diagram Generation (Sequence Diagram)

sequenceDiagram
    participant QueryInput
    participant API
    participant WikiGenerator
    participant SectionStore
    participant CacheStore
    participant TabStore
    participant RetryUtil
    QueryInput->>API: queryWikiProblemStream(rootPath, language)
    API-->>QueryInput: sectionsList
    QueryInput->>WikiGenerator: processSections(sectionsList)
    WikiGenerator->>SectionStore: update(identifiedSections)
    loop For each section
        SectionStore->>CacheStore: checkCache(section_id)
        CacheStore-->>SectionStore: cachedDiagram (if exists)
        alt If no cached diagram
            SectionStore->>API: generateSectionDiagram(rootPath, section)
            API-->>SectionStore: diagramData
            SectionStore->>RetryUtil: retryWithBackoff(generateSectionDiagram, section_id)
            RetryUtil-->>SectionStore: diagramData (after retries)
        else
            SectionStore->>TabStore: checkTabExists(section_id)
            TabStore-->>SectionStore: tabExists (boolean)
            alt If tab exists
                TabStore->>SectionStore: updateTabContent(section_id)
            end
        end
        SectionStore->>CacheStore: updateCache(section_id, diagramData)
        CacheStore-->>SectionStore: cacheUpdated
        SectionStore->>TabStore: openTabIfNotOpen(section_id)
        TabStore-->>SectionStore: tabOpened
    end
    SectionStore->>API: modifyOrCreateWiki(rootPath, updatedSections)
    API-->>SectionStore: success
    SectionStore->>TabStore: updateOpenTabs()
    TabStore-->>SectionStore: tabsUpdated
    SectionStore->>WikiGenerator: finalize()
    WikiGenerator-->>QueryInput: workflowComplete

Loading

Backend Logic Overview (Flowchart)

flowchart TD
  A[Client Request] --> B[API Layer]
  B --> C[WikiStructureRequest]
  C --> D{Comprehensive Mode?}
  D -->|Yes| E[Build Full Wiki]
  D -->|No| F[Build Concise Wiki]
  E --> G[Extract File Chunks]
  F --> G
  G --> H[Build Codebase Context]
  H --> I[RAG Query]
  I --> J[Retrieve Relevant Docs]
  J --> K[Generate Diagram Sections]
  K --> L[Build Mermaid Diagram]
  L --> M[Cache Diagram]
  M --> N[Add to RAG Database]
  N --> O[Return Diagram]
  B --> P[WikiPageRequest]
  P --> Q[Identify Section]
  Q --> R[Generate Section Diagram]
  R --> S[Cache Section]
  S --> T[Add to RAG Database]
  T --> U[Return Section Diagram]
  B --> V[Error Handling]
  V --> W[Log Error]
  W --> X[Return Error]
  style A fill:#e3f2fd,stroke:#1976d2,stroke-width:2px
  style O fill:#e8f5e9,stroke:#2e7d32,stroke-width:2px
  style U fill:#e8f5e9,stroke:#2e7d32,stroke-width:2px
  style X fill:#ffebee,stroke:#c62828,stroke-width:2px
  style D fill:#fff3e0,stroke:#ef6c00,stroke-width:2px

Loading

UI State Management and Caching (State Diagram)

stateDiagram-v2
  [*] --> Idle
  Idle --> Generating : User selects section
  Generating --> Cached : Diagram generated and cached
  Generating --> Error : Generation failed
  Cached --> Displayed : Diagram shown in UI
  Cached --> Regenerating : Cache invalidated
  Regenerating --> Cached : New diagram cached
  Error --> Retrying : Retry mechanism
  Retrying --> Generating : Retry attempt
  Retrying --> Error : Final failure
  Displayed --> ClosedTab : Tab closed
  ClosedTab --> Cached : Tab reopened
  Cached --> Invalidated : Cache cleared
  Invalidated --> Generating : Regenerate requested
  Idle --> CustomDiagram : User creates custom diagram
  CustomDiagram --> Generating : Custom prompt built
  Generating --> Cached : Custom diagram cached
  Cached --> UpdatedDiagram : Diagram updated
  UpdatedDiagram --> Cached : Updated cached
  Cached --> Corrupted : Diagram marked as corrupted
  Corrupted --> Regenerating : Regenerate corrupted diagram
  Regenerating --> Cached : Fixed diagram cached
  Idle --> LoadingHistory : Loading project history
  LoadingHistory --> Idle : History loaded
  Idle --> AnalyzingRepo : Repository analysis started
  AnalyzingRepo --> IdentifiedSections : Sections identified
  IdentifiedSections --> Generating : Diagram generation requested
  Generating --> Cached : Diagram cached
  Cached --> Displayed : Diagram displayed
  Displayed --> ClosedTab : Tab closed
  ClosedTab --> Cached : Tab reopened
  [*] --> Idle

Loading

Wiki Section Data Structures (Class Diagram)

classDiagram
  class WikiSection {
    +section_id: string
    +section_title: string
    +section_description: string
    +diagram_type: string
    +key_concepts: string[]
  }
  class DiagramData {
    +mermaid_code: string
    +description: string
    +is_valid: boolean
    +diagram_type: string
  }
  class DiagramSection {
    +status: string
    +section_id: string
    +section_title: string
    +diagram_data: DiagramData
  }
  class DiagramSectionsRequest {
    +root_path: string
    +language: string
  }
  class SectionDiagramRequest {
    +root_path: string
    +section_id: string
    +section_title: string
    +section_description: string
    +diagram_type: string
    +key_concepts: string[]
  }
  class WikiDiagramGenerator {
    -root_path: string
    -cache: WikiCache
    -rag: WikiRAG
    +generate_diagram_for_section(section: WikiSection): DiagramData
    +identify_diagram_sections(root_path: string, language: string): List~WikiSection~
  }
  class WikiCache {
    -cache_map: Map~string, DiagramData~
    +get(section_id: string): DiagramData
    +set(section_id: string, data: DiagramData): void
    +is_cached(section_id: string): boolean
  }
  class WikiRAG {
    +call(query: string, top_k: int): Tuple~str, List~Document~~
  }
  class DiagramViewer {
    -diagram_data: DiagramData
    +render(): void
  }
  class LeftPanel {
    -sections: List~WikiSection~
    -diagram_cache: Map~string, DiagramData~
    +update_section_diagrams(): void
  }
  class FolderPicker {
    -folder_path: string
    -sections: List~WikiSection~
    +generate_section_diagram(section: WikiSection): void
  }
  class TreeNode {
    -label: string
    -children: List~TreeNode~
    +expand(): void
  }
  class QueryDialog {
    -query: string
    +submit_query(): void
  }
  class DiagramTabs {
    -tabs: List~DiagramSection~
    +switch_tab(section_id: string): void
  }
  class DiagramStore {
    -diagram_data: Map~string, DiagramData~
    +get(section_id: string): DiagramData
    +set(section_id: string, data: DiagramData): void
  }
  WikiSection o-- DiagramData : contains
  DiagramSection o-- DiagramData : has
  WikiDiagramGenerator --> WikiCache : uses
  WikiDiagramGenerator --> WikiRAG : uses
  LeftPanel o-- WikiSection : displays
  LeftPanel o-- DiagramStore : updates
  FolderPicker o-- WikiSection : generates
  FolderPicker --> DiagramStore : caches
  TreeNode o-- TreeNode : child
  QueryDialog --> WikiRAG : queries
  DiagramTabs o-- DiagramSection : manages
  DiagramViewer --> DiagramData : renders
  DiagramStore o-- DiagramData : stores
  DiagramSectionsRequest --> WikiDiagramGenerator : triggers
  SectionDiagramRequest --> WikiDiagramGenerator : triggers
  note for WikiSection "Represents a section of the wiki with metadata for diagram generation"
  note for DiagramData "Holds the generated Mermaid code and metadata for a diagram"
  note for WikiDiagramGenerator "Main orchestrator for diagram generation and caching"
  note for WikiCache "Caching mechanism to avoid regenerating diagrams"
  note for WikiRAG "Retrieval-Augmented Generation system for context-aware diagram creation"
  note for LeftPanel "Frontend component managing the display of sections and diagrams"
  note for FolderPicker "Component for selecting folders and triggering diagram generation"
  note for DiagramTabs "Component managing open tabs for diagrams"
  note for DiagramViewer "Component responsible for rendering diagrams"
  note for DiagramStore "Svelte store for managing diagram data in frontend"
  note for TreeNode "Frontend component for rendering hierarchical project tree"
  note for QueryDialog "Dialog component for handling user queries"
  note for DiagramSectionsRequest "Request model for identifying diagram sections"
  note for SectionDiagramRequest "Request model for generating a specific diagram section"

Loading

How to Start

Prerequisites

• Python 3.12+
• Node.js 20+
• Ollama running locally
  • Install from ollama.ai
  • Pull models: ollama pull qwen3-coder:30b and ollama pull nomic-embed-text (based on the what you put in backend/.env file)
• Conda (recommended) or pip for Python packages

Setup

1. Create environment config

cd backend
cp .env.example .env
# Edit .env if needed (defaults work for most setups)

2. Install dependencies

# Backend
cd backend
conda env create -f environment.yml
conda activate DiagWiki

# Frontend
cd ../frontend
npm install

3. Launch

# From project root, in one command:
./launch.sh

Or run manually:

# Terminal 1 - Backend
ollama serve &
cd backend
conda activate DiagWiki
python main.py

# Terminal 2 - Frontend
cd frontend
npm run dev

Access application at http://localhost:5173 on default.

Technical Stack

Why these choices?

• Local Ollama + Python: Privacy-first. Your code never leaves your machine. LLMs run locally without sending data to external APIs.

• Python + FastAPI: Fast development for AI/RAG workflows. Direct integration with AdalFlow (RAG framework) and ChromaDB (vector database).

• Svelte: Lightweight and fast. Clean component model without virtual DOM overhead. Perfect for interactive diagram rendering with Mermaid.js.

• Mermaid.js: Industry-standard diagram syntax. Supports flowcharts, sequence diagrams, class diagrams, state diagrams, and ER diagrams.

Stack:

• Backend: Python, FastAPI, AdalFlow (RAG), Ollama (LLM)
• Frontend: SvelteKit, TypeScript, Mermaid.js

License

See LICENSE file.
