This project demonstrates the implementation of a segmented hospital network using the open-source OPNsense firewall and the Zenarmor Next-Generation Firewall (NGFW) plugin.
The entire infrastructure was built in a virtual lab environment using VMware Workstation, simulating a realistic hospital scenario with seven isolated network segments. The project covers network segmentation via VLANs, firewall rule creation, DHCP/DNS configuration, NGFW policy enforcement with Zenarmor (Deep Packet Inspection, App/Web Controls), connectivity testing, real-time log analysis, and simulated cyberattacks to validate policy effectiveness.
00:00 - Introduction to OPNsense
06:32 - Network Topology Overview
11:21 - Virtual Network Setup in VMware
13:11 - Installing OPNsense
14:22 - Initial CLI Configuration
16:58 - GUI Firewall Setup
18:21 - Interface Configuration
19:47 - DHCP Configuration for Surgical Network
22:03 - Connectivity Test
24:18 - General Firewall Rules Table
28:33 - Adding Firewall Rules
34:56 - Connectivity Test & Logs: RDP Attempt from Surgery to Medical Records
38:09 - Connectivity Test & Logs: SFTP Attempt from Pediatrics to Medical Records
47:35 - Zenarmor Overview
53:08 - Zenarmor Interface Integration
59:57 - Guest Network Policy Configuration
1:12:37 - Guest Network Policy Testing
1:17:50 - Medical Records Network Policy Configuration
1:19:53 - Medical Records Network Policy Testing
1:26:19 - Brute-force Attack Simulation from Guest to Medical Records (RDP)
1:35:22 - Final Thoughts
The simulated network consists of 7 segments, each representing a functional area within a hospital environment. VLANs are used to logically separate the zones, and all traffic is routed and filtered via OPNsense 25.1.
| VLAN ID | Zone | Subnet | OS | Role |
|---|---|---|---|---|
| 10 | Pediatrics | 192.168.10.0/24 | Windows | Clinical department |
| 20 | Surgery | 192.168.20.0/24 | Windows | Clinical department |
| 30 | Medical Records | 192.168.30.0/24 | Windows | Sensitive data storage (SFTP server) |
| 40 | Guest | 192.168.40.0/24 | Windows | Isolated guest access |
| 50 | Administration | 192.168.50.0/24 | Windows | Administrative operations |
| - | SysAdmin | 192.168.254.0/24 | Windows | Firewall management (LAN interface) |
| - | DMZ – Web Server | 172.16.1.0/24 | Ubuntu | Public-facing booking web service |
Note:
- The SysAdmin zone is directly connected to the OPNsense LAN interface for secure management access.
- The DMZ hosts a public-facing web service for hospital bookings, isolated on a dedicated interface.
| From \ To | Pediatrics | Surgery | Medical Records | Guest | Administration | SysAdmin | Internet | DMZ |
|---|---|---|---|---|---|---|---|---|
| Pediatrics | ✅ | ❌ | ✅ ¹ | ❌ | ❌ | ❌ | ✅ ² | ✅ |
| Surgery | ❌ | ✅ | ✅ ¹ | ❌ | ❌ | ❌ | ✅ ² | ✅ |
| Medical Rec. | ❌ ³ | ❌ ³ | ✅ | ❌ | ❌ ³ | ❌ | ❌ | ✅ |
| Guest | ❌ | ❌ | ❌ | ✅ | ❌ | ❌ | ✅ ² | ✅ |
| Administration | ❌ | ❌ | ✅ ¹ | ❌ | ✅ | ✅ | ✅ ² | ✅ ⁴ |
| SysAdmin | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ | ✅ |
| Internet | ❌ | ❌ | ❌ | ❌ | ❌ | ❌ | ✅ | ✅ |
| DMZ | ❌ | ❌ | ❌ | ❌ | ❌ | ❌ | ✅ ⁵ | ✅ |
Notes:
- SFTP only — read and transfer of own department records to local machine.
- Filtered via Zenarmor NGFW policy.
- Pull model — Medical Records does not initiate connections; other departments pull data from it.
- SFTP only — read and transfer of clinical records and bookings to local machine + web access.
- HTTPS only.
- Install and configure OPNsense 25.1 as the perimeter firewall on VMware Workstation
- Segment the network into seven isolated zones (five VLANs + SysAdmin + DMZ) with dedicated policies
- Configure DHCP, DNS, and static IP addressing for each segment with local domain resolution (
.ospedale.lan) - Integrate and enable Zenarmor as NGFW for Layer 7 traffic inspection and advanced policy enforcement
- Apply custom firewall rules implementing the principle of least privilege across all internal segments
- Configure SFTP-only access between clinical departments and Medical Records using Bitvise SSH Server with chroot isolation
- Define Zenarmor policies for Guest and Medical Records networks, including App Controls, Web Controls, Security categories, and per-IP whitelist exceptions
- Perform connectivity tests and validate rules using real-time firewall logs (OPNsense Live View)
- Simulate a brute-force RDP attack from the Guest network (Kali Linux + Ncrack) to validate Zenarmor detection and blocking capabilities
- Use OPNsense aliases to simplify rule management for multi-network blocking
- Stateful Firewall with per-interface rule management across seven network segments
- VLAN-based segmentation for logical isolation of hospital departments
- DHCP Server with custom address pools and domain names per network segment (e.g.,
chirurgia.ospedale.lan) - DNS Resolver acting as local DNS with DNSSEC support, using Cloudflare upstream (1.1.1.1 / 1.0.0.1)
- Zenarmor NGFW integration providing Deep Packet Inspection (DPI) at Layer 7
- App Controls for blocking application-level traffic (Social Networks, Gaming, Streaming, Proxy, Remote Access)
- Web Controls for category-based website filtering (Adult, Gambling, Hate/Violence)
- Essential & Advanced Security policies blocking malware, phishing, botnet C&C, DNS tunneling, spyware, and newly registered domains
- Per-IP whitelist exceptions within Zenarmor policies for granular access control
- Alias-based rules (RetiLocaliOspedale) for efficient multi-network blocking in a single firewall rule
- SFTP chroot isolation via Bitvise SSH Server — per-department folders with read-only access
- Real-time log analysis via OPNsense Live View and Zenarmor Reports (Connections, Threats, Blocks, Web, DNS, TLS)
- Live Sessions monitoring for dynamic traffic analysis and anomaly detection
- Brute-force attack simulation (Ncrack RDP) with real-time Zenarmor detection and blocking
- AMTSO security testing to validate malware/virus blocking policies on the Guest network
- OPNsense 25.1 (FreeBSD-based open-source firewall)
- Zenarmor (NGFW plugin with DPI engine)
- VMware Workstation (virtualization platform)
- Windows (hospital department environments)
- Kali Linux (attack simulation — Ncrack brute-force)
- Ubuntu Server (DMZ web service)
- Bitvise SSH Server (SFTP server with chroot and per-user permissions)
- WinSCP (SFTP client for secure file transfer)
This project is released under the MIT License.
Free to use for educational and research purposes. Please credit the author where applicable.
Created by Alberto Cirillo — 2025
