Moving Stylus

A compiler that translates Move smart contracts to WASM to run on Arbitrum Stylus, enabling Move development in EVM-compatible environments.

Built by Rather Labs.

Overview

This repository contains the source code to compile the Move language to WASM, for running it in Arbitrum's Stylus Environment.

The Move-to-Stylus compiler translates Move bytecode directly into WASM. This approach:

• Leverages the existing Move compiler for type checks and validations.
• Avoids modifying the Move compiler.
• Focuses on generating Stylus-compatible WASM modules.

Disclaimer

Warning

The code has not been audited and may contain security vulnerabilities or bugs. Use at your own risk.

Documentation

You can find the documentation here.

Move compiler

The Move compiler, based on the Sui Move implementation, passes and validate the move code through several stages and return Move-bytecode.

Move bytecode is a high-level intermediate representation interpreted by the Move Virtual Machine (MoveVM). For example:

const ITEM_PRICE: u64 = 100;

public fun hello_world(): u64 {
    ITEM_PRICE
}

// Move bytecode v6
module 0.hello_world {
    public hello_world(): u64 {
        B0:
            0: LdConst[0](u64: 100)
            1: Ret
    }
    Constants [
        0 => u64: 100
    ]
}

Translation Approach

Why Direct Translation?

• Advantages:
  • Simplifies the setup by avoiding external backends like LLVM.
  • Embeds Stylus-specific interfaces directly in the WASM output.
  • Keeps the entire toolchain in Rust.
• Trade-offs:
  • Lacks optimization passes (relies on the Move compiler).
  • Requires implementing features like type operations and testing frameworks from scratch.

---

WASM Compilation

Stylus programs require a specific structure and interface in WASM. The user_entrypoint function serves as the main entry point, handling all function calls. It uses Stylus host functions to read arguments and write results:

pub extern "vm_hooks" fn read_args(dest: *u8) void;
pub extern "vm_hooks" fn write_result(data: *const u8, len: usize) void;

A basic entry point example (pseudocode):

fn user_entrypoint(len: i32) -> i32 {
    let buffer = read_args(len);
    unpack_abi(buffer); // Load data into the stack
    let return_value = transfer(); // Example function call
    write_result(return_value, len(return_value));
    0 // Success
}

Stylus Router for Move Contracts

To expose all public functions in a Move contract, a single user_entrypoint function acts as a router. It uses the function selector (first 4 bytes of calldata) to route calls to the appropriate function (pseudocode):

fn user_entrypoint(len: i32) -> i32 {
    let buffer = vec![len];
    read_args(&mut buffer);

    let selector = &buffer[0..4];
    match selector {
        function_x_selector => {
            unpack_abi(buffer);
            let return_value = call_function_x();
            write_result(return_value, len(return_value));
        },
        function_y_selector => {
            unpack_abi(buffer);
            let return_value = call_function_y();
            write_result(return_value, len(return_value));
        },
        _ => panic!("Unknown function selector"),
    }

    0 // Success
}

Tooling

The entire compiler is built in Rust, using the following libraries:

• Move Compiler: Sui Move.
• WASM Generation: Walrus for building WASM modules.
• WASM Debugging: wasmprinter and wasmparser.
• WASM Testing: Wasmtime for creating a WASM runtime in Rust.

Build instructions

Set up the stylus environment and install required tools:

make setup-stylus
make install-wasm-tools

Or install the move-stylus CLI tool:

make install

Examples

In the examples/ folder, several fully functional contracts showcase different aspects of the Move language semantics, including core examples, token standards, advanced patterns, and testing & demonstration contracts.

build the example package:

make build-example

deploy to arbitrum dev node (local):

make deploy-example
make deploy-example-2
make deploy-example-primitives
make deploy-counter
make deploy-counter-with-init

Check Makefile for more contracts.

run test interactions (make sure to setup a .env file):

make example-interaction
make example-interaction-2
make example-interaction-primitives
make example-counter
make example-counter-with-init
make example-dog-walker

Check Makefile for more contracts.

License

This project is developed by Rather Labs and licensed under the Business Source License 1.1
