swaylock-effects

Swaylock-effects is a fork of swaylock which adds built-in screenshots and image manipulation effects like blurring. It's inspired by i3lock-color, although the feature sets aren't perfectly overlapping.

This repository (hboetes/swaylock-effects) is a fork of mortie/swaylock-effects, via jirutka/swaylock-effects, both of which are now unmaintained.

Security fixes in this fork

The following bugs were found and fixed during a code audit of the inherited codebase:

• pam.c: shadowed pam_status variable — the inner loop redeclared pam_status, shadowing the outer variable. As a result, pam_end() and the final exit() always received PAM_SUCCESS regardless of the actual authentication result.
• loop.c: unsafe realloc() in loop_add_fd() — assigning realloc() directly to loop->fds meant a failed allocation would set loop->fds to NULL while leaking the old allocation, followed immediately by a NULL dereference write.
• cairo.c: unchecked malloc() in cairo_surface_duplicate() — the result was passed directly to memcpy() without a NULL check.
• effects.c: unchecked malloc() in effect_blur() — the scratch buffer was passed directly to blur_once() without a NULL check.
• effects.c: --effect-custom removed — this feature compiled and loaded user-supplied C files as lock screen effects at runtime, invoking cc(1) from within the lock screen process. It had no known users and has been removed along with --time-effects.

Example Command

swaylock \
    --screenshots \
    --clock \
    --indicator \
    --indicator-radius 100 \
    --indicator-thickness 7 \
    --effect-blur 7x5 \
    --effect-vignette 0.5:0.5 \
    --ring-color bb00cc \
    --key-hl-color 880033 \
    --line-color 00000000 \
    --inside-color 00000088 \
    --separator-color 00000000 \
    --grace 2 \
    --fade-in 0.2

New Features

The main new features compared to upstream swaylock are:

• --screenshots to use screenshots instead of an image on disk or a color
• --clock to show date/time in the indicator
  • Use --indicator to make the indicator always active
  • Use --timestr and --datestr to set the date/time formats (using strftime-style formatting)
• --submit-on-touch to use your touchscreen to submit a password. If you can unlock your device with anything else than your password, this might come helpful to trigger PAM's authentication process.
• --grace <seconds> to set a password grace period, so that the password isn't required to unlock until some number of seconds have passed.
  • Used together with --indicator, the indicator is always shown, even in the grace period.
  • Used together with --indicator-idle-visible, the indicator is only visible after the grace period.
  • By default, a key press, a mouse event or a touch event will unlock during the grace period. Use --grace-no-mouse to not unlock as a response to a mouse event, and --grace-no-touch to not unlock as a response to a touch event.
• --fade-in <seconds> to make the lock screen fade in.
• --indicator-image <path> to display an image inside the indicator.
• --text-clear <string>, --text-caps-lock <string>, --text-ver <string>, and --text-wrong <string> to change the texts displayed inside the indicator.
• -p, --fingerprint to unlock with a fingerprint scanner via fprintd.
• -P, --fingerprint-on-demand for external fingerprint scanners that time out after ~2 minutes. Press ESC or C-u to activate the scanner after locking.
• --image <path> now accepts a directory, picking a random image file from it.
• Various effects which can be applied to the background image
  • --effect-blur <radius>x<times>: Blur the image (thanks to yvbbrjdr's fast box blur algorithm in i3lock-fancy-rapid)
  • --effect-pixelate <factor>: Pixelate the image.
  • --effect-scale <scale>: Scale the image by a factor. This can be used to make other effects faster if you don't need the full resolution.
  • --effect-greyscale: Make the image greyscale.
  • --effect-vignette <base>:<factor>: Apply a vignette effect (range is 0-1).
  • --effect-compose <position>;<size>;<gravity>;<path>: Overlay another image.

New feature ideas are welcome as issues (though I may never get around to implement them), new feature implementations are welcome as pull requests :)

Installation

Install dependencies:

• meson *
• wayland
• wayland-protocols *
• libxkbcommon
• cairo
• gdk-pixbuf2 **
• pam (optional)
• fprintd (optional: fingerprint support)
• scdoc (optional: man pages) *
• git *
• openmp (if using a compiler other than GCC)

*Compile-time dep

**Optional: required for background images other than PNG

Run these commands:

meson setup build
meson compile -C build
sudo meson install -C build

Check meson_options.txt for build options. So for example, if you want to build with fingerprint support, use meson setup build -Dfingerprint=enabled

On systems without PAM, you need to suid the swaylock binary:

sudo chmod a+s /usr/local/bin/swaylock

Swaylock will drop root permissions shortly after startup.

Effects

Blur

--effect-blur <radius>x<times>: Blur the image.

<radius> is a number specifying how big the blur is, <times> is a number which specifies essentially how high quality the blur is (i.e how closely the effect will resemble a true gaussian blur).

Pixelate

--effect-pixelate <factor>: Pixelate the image.

<factor> is the amount of pixelation; a value of 10 will make each 10x10 square of pixels the same color.

Scale

--effect-scale <scale>: Scale the image by a factor.

This effect scales the internal buffer. This has a few uses:

• Use --effect-scale in combination with --scaling to create a zoom effect: --effect-scale 1.1 --scaling center
• Speed up other effects by making the resolution smaller: with --effect-scale 0.5 --effect-blur 7x5 --effect-scale 2, swaylock-effect needs to blur only 1/4 as many pixels.

Greyscale

--effect-greyscale: Make the displayed image greyscale.

Vignette

--effect-vignette <base>:<factor>: Apply a vignette effect. Base and factor should be between 0 and 1.

Compose

--effect-compose "<position>;<size>;<gravity>;<path>": Overlay another image to your lock screen.

• <position>: Optional. The position on the screen to put the image, as <x>,<y>.
  • Can be a percentage (10%,10%), a number of pixels (20,20), or a mix (30%,40).
  • A negative number indicates that number of pixels away from the right/bottom instead of from the top/left; -1,-1 would be the bottom right pixel.
  • Default: 50%,50%.
• <size>: Optional. The size of the image on the screen, as <w>x<h>.
  • Can be a percentage (10%x10%), a number of pixels (20x20), or a mix (30%x40).
  • If the width is -1, the width is figured out based on the height and aspect ratio.
  • If the height is -1, the height is figured out based on the width and aspect ratio.
  • Default: The size of the image file.
• <gravity>: Optional. Determine which point of the image is placed at <position>.
  • Possible values: center, north, south, west, east, northwest, northeast, southwest, southeast.
  • With a <gravity> of northwest, <position> gives the location of the top/left corner of the image; with southeast, <position> controls the bottom/right corner, center controls the middle of the image, etc.
  • Default: center if no <position> is given; otherwise, intelligently decide a gravity based on position (10,10 -> northwest, -10,10 -> northeast, etc).
• <path>: The path to an image file.

This command requires swaylock-effects to be compiled with gdk-pixbuf2. It supports all image formats gdk-pixbuf2 supports; on my system, that's png, jpeg, gif, svg, bmp, ico, tiff, wmf, ani, icns, pnm, qtif, tga, xbm and xpm.

Integration into your window manager configuration

To make swaylock-effect easy to start from your window manager you could write a wrapper script, and add it to your PATH, something like this:

#!/bin/zsh

case "$1" in
    now)
        grace=0
        fade=0
        ;;
    *)
        grace=10
        fade=5
    ;;
esac

swaylock \
    --clock \
    --effect-vignette 0.5:0.5 \
    --fade-in $fade \
    --fingerprint \
    --indicator-caps-lock \
    --indicator-radius 100 \
    --indicator-thickness 7 \
    --inside-color 00000088 \
    --key-hl-color 880033 \
    --line-color 00000000 \
    --ring-color bb00cc \
    --separator-color 00000000 \
    --image $HOME/Wallpapers/lockscreen \
    --grace $grace
