Django‑OpenAI Chatbot

This project is a Django‑based web application that integrates with OpenAI to provide a chatbot experience through a browser UI.

The app runs as a standard Django project (django_chatbot) with a chatbot app, served by Gunicorn behind NGINX in Docker. Static files are collected into staticfiles and served directly by NGINX.

The repository includes:

• A Dockerfile for building the Django application image
• A docker-compose.yml stack with a Django/Gunicorn container and an NGINX reverse proxy
• Basic NGINX configuration under ./nginx

To enable HTTPS support, you will need to extend the NGINX configuration with SSL directives and provide certificates (see HTTPS / TLS).

Note Some operational details (for example, exact OpenAI model names or advanced deployment guidance) are intentionally left as TODOs where they are not explicitly configured in this repository.

---

Tech stack

• Language: Python 3.11 (Docker base image); supports Python >=3.9.13 per pyproject.toml
• Web framework: Django 4.2.2 (django_chatbot project, chatbot app)
• ASGI/WSGI server: Gunicorn
• Reverse proxy / static: NGINX
• Database: SQLite (file db.sqlite3, configurable via DJANGO_DB_PATH)
• OpenAI integration: openai Python SDK (v2.x)
• Markdown rendering: markdown + pymdown-extensions
• Containerization: Docker + docker‑compose
• Dependency management:
  • requirements.txt for runtime
  • pyproject.toml (PEP 621 metadata, alternative dependency declaration)

---

Requirements

Local (no Docker)

• Python 3.11 (recommended; matches Docker image)
• pip
• (Optional but recommended) virtualenv (python -m venv)

Docker setup

• Docker
• docker‑compose

---

Getting started

1. Clone the repository

git clone https://github.com/yourgithubusername/django-openai-chatbot.git
cd django-openai-chatbot

You can rename the Git remote/URL to your fork as needed.

---

Running locally (without Docker)

1. Create and activate a virtual environment

python3.11 -m venv .venv
source .venv/bin/activate

On Windows (PowerShell):

python -m venv .venv
.venv\Scripts\Activate.ps1

2. Install dependencies

pip install --upgrade pip
pip install -r requirements.txt

3. Configure environment

At minimum for development:

export DJANGO_DEBUG=True
export OPENAI_API_KEY=sk-...  # required if you want to call the OpenAI API

Optional environment variables are described in Environment variables.

You can set these in your shell profile (.bashrc, .zshrc, etc.) or use a .env loader of your choice (not provided by default).

4. Initialize the database and collect static files

python manage.py migrate
python manage.py collectstatic --no-input

5. Run the development server

python manage.py runserver 0.0.0.0:8000

Open your browser at:

• http://localhost:8000

---

Running with Docker and docker‑compose

The recommended way to run the full stack (Django via Gunicorn behind NGINX) is via docker-compose.

1. Set required environment

export OPENAI_API_KEY=sk-...

You may also export DJANGO_DEBUG=True if you want debug settings inside the container, but this is not strictly required for basic usage.

2. Build and start the services

docker-compose up --build

This will:

• Build the django_app image using the provided Dockerfile
• Start django_app with Gunicorn using /app/gunicorn.conf.py
• Start an nginx container listening on port 8888
• Mount ./staticfiles into the NGINX container for static assets

Once containers are up, access the application via NGINX at:

• http://localhost:8888

3. Development server via Docker (optional)

For development, you may want to run Django’s development server instead of Gunicorn inside the django_app container. One option is to temporarily override the command in docker-compose.yml:

services:
  django_app:
    command: python manage.py runserver 0.0.0.0:8000

Then start the stack:

docker-compose up

TODO: Provide a dedicated docker-compose.override.yml example for dev mode.

---

Entry points and scripts

• Django management: manage.py
  • Example: python manage.py runserver 0.0.0.0:8000
• Gunicorn (Docker):
  • Defined in docker-compose.yml:

    gunicorn -c /app/gunicorn.conf.py django_chatbot.wsgi:application --bind 0.0.0.0:8000

• Container entrypoint: entrypoint.sh
  • Collects static files and runs migrations the first time db.sqlite3 is absent, then execs the container command.
• Local Gunicorn helper script: start_gunicorn.sh
  • Activates a local virtualenv (.venv) and starts Gunicorn with

    gunicorn -c ./gunicorn.conf.py django_chatbot.wsgi:application --bind 0.0.0.0:8000 --workers 3

  • This script assumes a particular directory layout and shell configuration; adjust it to your environment or treat it as an example.

---

Environment variables

The following environment variables are read by the project (see django_chatbot/settings.py and docker-compose.yml):

• DJANGO_SECRET_KEY

  • Secret key for Django.
  • If not set, a random key is generated at startup (suitable for local development only).

• DJANGO_DEBUG

  • Set to the string True to enable Django DEBUG mode.
  • Example: export DJANGO_DEBUG=True

• DJANGO_DB_PATH

  • Optional; directory path for the SQLite database.
  • If set, Django uses <DJANGO_DB_PATH>/db.sqlite3 if it exists; otherwise it falls back to <BASE_DIR>/db.sqlite3.

• OPENAI_API_KEY

  • Required to make outbound OpenAI requests.
  • Passed into the Django container in docker-compose.yml.

TODO: Document any additional OpenAI‑specific settings (e.g., default model, temperature) if configuration is added in the codebase.

---

Tests

The project uses Django’s built‑in test runner (no pytest).

Running all tests

python manage.py test -v 2

At the time of writing, there is a single test class in chatbot/tests.py:

• FiltersTest.test_markdown_output — checks the HTML produced by the markdown_to_html template filter.

Known issue: This test is currently failing due to strict HTML expectations that may not match the exact output of the Markdown renderer. See chatbot/tests.py and chatbot/templatetags/custom_filters.py before relying on it as a regression test.

Running a specific test

python manage.py test chatbot.tests.FiltersTest -v 2
python manage.py test chatbot.tests.FiltersTest.test_markdown_output -v 2

Tests and package layout

• There is both a module chatbot/tests.py and a package directory chatbot/tests/.
• In Python, the module chatbot.tests shadows the package chatbot/tests/, so Django will not discover tests inside chatbot/tests/ via labels like chatbot.tests.test_smoke.

Current recommendations for adding tests:

• Add new tests to chatbot/tests.py or create new top‑level modules such as chatbot/test_*.py.
• Run them with labels like:

  python manage.py test chatbot.test_example -v 2

TODO: Refactor the tests layout (for example, rename chatbot/tests.py to chatbot/test_filters.py) so that chatbot/tests/ can be used as a proper package.

Running tests in Docker

Inside the Django app container:

docker-compose run --rm django_app python manage.py test -v 2
docker-compose run --rm django_app python manage.py test chatbot.tests.FiltersTest -v 2

The test database uses SQLite (in memory by default) for speed.

---

Project structure

High‑level layout (non‑exhaustive):

django-openai-chatbot/
├── chatbot/                  # Django app with chatbot views, models, templates, tests
│   ├── management/           # Custom management commands (if any)
│   ├── migrations/           # Django migrations
│   ├── templatetags/         # Custom template tags/filters (e.g., markdown_to_html)
│   ├── tests.py              # Main test module (currently shadows chatbot/tests/)
│   └── tests/                # Additional tests (not fully wired due to module name clash)
├── django_chatbot/           # Django project configuration (settings, URLs, WSGI)
├── templates/                # HTML templates
├── static/                   # Source static assets (CSS, JS, images)
├── staticfiles/              # Collected static files (built via collectstatic)
├── nginx/                    # NGINX configuration
├── certs/                    # Certificate-related directories (hooks; certs not included)
├── Dockerfile                # Django application image definition
├── docker-compose.yml        # Multi‑container stack (Django + NGINX)
├── gunicorn.conf.py          # Gunicorn configuration
├── entrypoint.sh             # Container entrypoint script
├── start_gunicorn.sh         # Helper script for running Gunicorn locally
├── manage.py                 # Django management script
├── requirements.txt          # Runtime dependencies
├── pyproject.toml            # Project metadata and dependencies
├── LICENSE                   # MIT license
└── README.md                 # This file

TODO: Document key Django views, URL routes, and templates once the chatbot UI and API surface are finalized.

---

Static files, Gunicorn, and NGINX

• Static files

  • STATIC_URL = '/static/'
  • STATIC_ROOT = BASE_DIR / 'staticfiles'
  • STATICFILES_DIRS = [ BASE_DIR / 'static' ]
  • In the Docker stack, NGINX serves /static/ from /app/staticfiles, which is mapped to ./staticfiles on the host.

• Gunicorn

  • Started in Docker with:

    gunicorn -c /app/gunicorn.conf.py django_chatbot.wsgi:application --bind 0.0.0.0:8000

  • Logging: access and error logs go to stdout/stderr; log level is error by default; timeout is 120s.

• NGINX

  • Listens on port 8888, proxies to django_app:8000.
  • Static location /static/ is mapped to /app/staticfiles.

---

HTTPS / TLS

To enable HTTPS support with NGINX you will need to:

1. Obtain TLS certificates (for example via Let’s Encrypt or another CA).

2. Mount the certificates into the NGINX container (e.g., under /etc/letsencrypt).

3. Update the NGINX configuration in nginx/default.conf to include directives such as:

   ssl_certificate /path/to/fullchain.pem;
   ssl_certificate_key /path/to/privkey.pem;

4. Enable the SSL server block and redirect HTTP to HTTPS as required.

Consult the official NGINX documentation for detailed SSL/TLS configuration options.

TODO: Provide a concrete example default.conf with SSL blocks enabled and documented volume mounts for certificates.

---

Contributing

Contributions are welcome. A typical workflow is:

1. Fork this repository.
2. Create a new branch: git checkout -b feature/my-feature.
3. Make your changes and add tests where appropriate.
4. Run the test suite: python manage.py test -v 2 (or the relevant subset).
5. Commit with a descriptive message: git commit -m "Describe your change".
6. Push to your fork: git push origin feature/my-feature.
7. Open a Pull Request against the main repository.

For more details, see GitHub’s documentation on creating a pull request.

---

License

This project is licensed under the MIT License.

Copyright © 2024 Alexey Bogomolov
