LOVJ - LÖVE2D VJing Framework

📖 Overview

LOVJ is a framework based on LÖVE2D, designed as a live-coding and interactive VJing environment. It's primarily aimed at live music performances, allowing for the creation, sequencing, and mixing of video patches.

✨ Features

Current

• Interactive Controls: Control patches through mouse, keyboard, touch and gamepads.
• GLSL Shaders: Builtin support for GLSL shaders, write your own filters, ray-marchers, etc.
• Spout Integration: Stream video to and from other applications using Spout.
• Savestates: Quickly save and recall the internal state of patches.
• Patch-based Architecture: Modular design based on video patches that can be loaded, sequenced, and mixed.
• MIDI Support: Connect MIDI controllers for real-time parameter control and patch triggering.
• OSC Networking: Built-in OSC server for external control and integration with other applications.

Planned

• Live-Coding: Edit code on-the-fly with hot-reloading capabilities.

📋 Prerequisites

• LÖVE version 11.4 or higher.

🚀 Installation

1. Clone the repository with all submodules:

   git clone --recurse-submodules https://github.com/merumerutho/LOVJ.git

2. Add the LÖVE binary directory to your system's PATH variable.
3. Navigate to the cloned repository's root directory (the one containing main.lua).
4. Run the application with the following command:

   love .

🔧 Usage

General Controls

• F1 - F12: Switch between loaded patches.
• Ctrl + Enter: Toggle fullscreen mode.
• Ctrl + S: Toggle shaders on or off.
• Ctrl + U: Change the upscaling mode.
• S: Cycle through available visual effects.

MIDI and OSC Control

LOVJ supports external control through MIDI and OSC protocols:

MIDI Setup

1. Configure MIDI connections in cfg/cfg_midi_mapping.lua
2. Set enabled = true for your MIDI device in the connections section
3. Map MIDI CC, notes, and program changes to LOVJ commands
4. Use auto-detection or specify device names/indices

Example MIDI mappings:

• CC1: Switch patches
• CC7: Global volume control
• Notes 60-67: Trigger patches 1-8
• Program changes: Load specific patches

OSC Setup

1. Configure OSC connections in cfg/cfg_osc_mapping.lua
2. Set connection address, port, and enable the connection
3. Map OSC addresses to LOVJ commands using direct or pattern mappings

Example OSC addresses:

• /lovj/global/selectedPatch <slot>: Switch to patch slot
• /lovj/patch/<slot>/param/<name> <value>: Set patch parameter
• /lovj/shader/<slot>/<layer>/param/<name> <value>: Set shader parameter
• /lovj/system/fullscreen <0|1>: Toggle fullscreen

⚙️ Configuration (Optional)

LOVJ's behavior can be customized through the various .lua files in the cfg directory. Here are some of the key configuration files:

• cfg/cfg_app.lua: Application title and icon.
• cfg/cfg_connections.lua: UDP and OSC connection settings.
• cfg/cfg_controls.lua: General (non-patch-specific) input controls.
• cfg/cfg_patches.lua: Default patch and the list of patches to load.
• cfg/cfg_screen.lua: Screen resolution and windowing settings.
• cfg/cfg_shaders.lua: Shader configurations.
• cfg/cfg_spout.lua: Spout sender and receiver settings.

Porting GLSL shaders

You can port GLSL shaders to LOVJ by creating a new patch in postProcess and readapt the shader code.

This is how a GLSL shader should be implemented to be compatible with LOVJ.

// @param vec4  _param1 {0.0, 1.0, 0.0, 1.0} //
// @param vec2  _param2 {-0.1, 0.1} //
// @param float _param3 -0.1 //

extern vec4  _param1;
extern vec2  _param2;
extern float _param3;

vec4 effect(vec4 color, Image tex, vec2 texture_coords, vec2 screen_coords) {
    -- your shader code here  (must include usage of _param1, _param2, _param3)
}

Notice the @param <type> <name> <default_value> tags.

They are used to automatically instance dedicated resources for each shader parameter, with a default initial value.

These are instanced with the following name structure: <shadername_paramname>

Passing value to shader

To update the value of the shader parameter, one can use the following in the update cycle, as an example:

-- cfg/cfg_shaders.lua
if string.find(shader.name, "yourShaderName") then
    shader.object:send("_param3", s:get("yourShaderName__param3"))
end

And to change the value:

-- cfg/cfg_shaders.lua
-- ...
-- yourShaderName
if kp.isDown("m") then
    if kp.isDown("up") then s:set("yourShaderName__param3", (s:get("yourShaderName__param3") + 0.1)) end
    if kp.isDown("down") then s:set("yourShaderName__param3", (s:get("yourShaderName__param3") - 0.1)) end
end

Feel free to adapt the parameter name and the value to your needs, this is just an example that binds the parameter to the M key and allows to change it with the UP and DOWN arrow keys.

Then, in order to use the shader, you need to cycle through the effects with the S key, until you reach the desired effect.

🤝 Contributing

Contributions are welcome! Please feel free to open an issue or submit a pull request.

📄 License

This project is licensed under the GPL-3.0 License - see the LICENSE file for details.

🙏 Acknowledgments

• lick: For the live-coding features.
• json.lua: JSON library.
• Spout: Spout library for video sharing.
• SiENcE/lovemidi SiENcE for lovemidi.
