This repository is the code for my final year project, dealing with decentralised approaches to graph colouring.
(click to watch)
- clone the repo
- run make
make- alternatively manually compile the src files with whatever compiler you prefer
- Run the tests to see that all of the logic works alright on your machine
- Compile a test executable with
make compile_test- run the test executable to run the tests
- Run the executable you compiled from the command line with some variation of the following options
usage: colouring.exe [options]
options:
-h print these instructions
-n [integer] set the number of nodes in the graph
default is 10
-M [integer] set the max iterations
default is 50000 (plenty)
this limits the amount of time the agent algorithm can run for
-c [integer] colour lower bound
if you set this parameter, the algorithm will try and colour the graph
with that many colours
if it fails to find a solution, it will increment the number of colours
until it reaches the upper bound
-C [integer] colour upper bound
the default is determined by a brute force centralised approach
this paramter will have no effect if the lower bound is not also set
can be used to ensure that the solution is optimal or to force conflicts
-S [name/path] set the save mode on
flag which sets whether the results are saved to a file called results.csv
the default is false
the name/path is optional, but allows for custom names or paths if included
-A [integer] number of automatic runs
default is 1 (run the program once)
increasing the number will run the program that number of times
can be used to save multiple runs of the same settings
-a [integer] number of agents
sets the number of agents (active nodes) in the colouring algorithm
the default is an agent at every vertex
maximum is the number of nodes in the graph
-m [integer] number of agent moves
sets the number of moves an agent makes on each "turn"
the default is 0 (agents are stationary)
-v set visualise mode on
prints the graph when the colouring is complete
enters the user into an interactive traversal mode
can be useful to help visualise graphs
default is off
-g [generator] set the generator
sets the graph generator function to use
there are currently two different types of graphs you can use
r: random graph; each edge has a p% chance of existing (default)
options:
-p [float] probability (as a floating point number between 0 and 1)
probability that each edge of the graph exists
default is 0.5
o: ring graph; undirected graph where each node has two neighbours
b: bipartite graph; a graph of two disjoint subsets
options:
-s [integer] set one; the number of nodes in the first subset
the default is to split the number of nodes in two
-k [kernel] set the colouring kernel
sets the kernel used to colour the nodes
options include:
m: local minimum (default); applies the local minimum colour
r: random kernel; picks a colour between 1 and max if in conflict
d: colour-blind decrement; decrements colour if in conflict
i: colour-blind increment; increments colour if in conflict
a: amongus kernel; introduces a bad actor (colours with m)
-d [kernel] set the dynamic kernel
sets the kernel used to modify the topology of the graph
options include:
x: no dynamic kernel (default)
e: possibly remove edge
n: possibly remove node
o: remove orphan nodes
t: remove nodes based on a threshold
a: possibly remove the agent, but not the node
-w [kernel] set the movement kernel
sets the kernel used to move agents between nodes
options include:
x: no movement kernel (default)
r: random movement kernel
o: optimal movement kernel
-K [config] set kernel config
sets the kernel config based on the provided string
the string is parsed in the format [colour, dynamic, movement]
for example, the default configuration is 'mxx'
colour-blind decrement with possible edge removal would be 'dex'
colour a ring graph with 51 nodes and 10000 iterations max
./colouring.exe -n 51 -g o -M 10000colour a random graph which has a probability of 30% that each edge exists
./colouring.exe -p 0.3colour a bipartite graph with 2 nodes in the first set and 4 in the second
./colouring.exe -g b -n 6 -s 2colour a connected random graph with 1001 nodes, using at least 5 colours and at most 50 colours
./colouring.exe -n 1001 -p 1 -c 5 -C 50colour a random graph with 300 nodes and 70% probability for each edge, using 50 agents that move twice on each turn, save the results and run it on 10 different graphs
./colouring.exe -n 300 -p 0.7 -a 50 -m 2 -A 10 -Scolour a random graph using the configuration of the decrementing kernel for colouring and the node removal kernel as a dynamic aspect, then view the graph in the interactive mode when finished
./colouring.exe -n 100 -p 0.5 -K dnx -vIf you want, feel free to fork the repository in order to extend the code with new kernels in order to run new experiments. In order to add a new kernel, you simply need to do the following:
- navigate to the relevant file
- add the new function, following the established function signature
- add an option for it in the main function (
colouring.c) - add a test (optional)
You can then use the kernel in your experiments
