Computer Link Protocol for .NET

A user-focused .NET library for JTEKT TOYOPUC Computer Link communication. The recommended entry point is the high-level queued client created by ToyopucDeviceClientFactory.

This README intentionally covers the public high-level API only:

• ToyopucConnectionOptions
• ToyopucDeviceClientFactory.OpenAndConnectAsync
• ReadAsync / WriteAsync
• ReadTypedAsync / WriteTypedAsync
• WriteBitInWordAsync
• ReadManyAsync / ReadNamedAsync
• PollAsync
• ReadWordsSingleRequestAsync / ReadDWordsSingleRequestAsync
• ReadWordsChunkedAsync / ReadDWordsChunkedAsync
• ReadFrAsync / WriteFrAsync / CommitFrAsync

Quick Start

Installation

• Package page: https://www.nuget.org/packages/PlcComm.Toyopuc/

dotnet add package PlcComm.Toyopuc

Or add a package reference directly:

<PackageReference Include="PlcComm.Toyopuc" Version="0.1.5" />

High-Level Example

using PlcComm.Toyopuc;

var options = new ToyopucConnectionOptions("192.168.250.100")
{
    Port = 1025,
    DeviceProfile = "TOYOPUC-Plus:Plus Extended mode",
};

await using var client = await ToyopucDeviceClientFactory.OpenAndConnectAsync(options);

var word = await client.ReadAsync("P1-D0000");
Console.WriteLine($"P1-D0000 = {word}");

await client.WriteAsync("P1-D0001", 1234);
await client.WriteAsync("P1-M0000", 1);

var typed = await client.ReadTypedAsync("P1-D0200", "F");
Console.WriteLine($"P1-D0200:F = {typed}");

var snapshot = await client.ReadNamedAsync(["P1-D0000", "P1-D0200:F", "P1-D0000.0"]);
Console.WriteLine(snapshot["P1-D0000"]);

Basic area families P/K/V/T/C/L/X/Y/M/S/N/R/D require a P1-, P2-, or P3- prefix.

Supported PLC Registers

Start with these public high-level families first:

• prefixed word/register areas: P1-D0000, P1-S0000, P1-N0100, P1-R0000
• prefixed bit/control areas: P1-M0000, P1-X0000, P1-Y0000, P1-T0000
• extension areas: ES0000, EN0000
• FR storage: FR000000
• typed and bit views: P1-D0100:S, P1-D0200:D, P1-D0300:F, P1-D0000.3

See the full public table in Supported PLC Registers.

Public Documentation

• Getting Started
• Supported PLC Registers
• Latest Communication Verification
• User Guide
• Examples Guide
• High-Level API Contract

Start with these example programs:

• examples/PlcComm.Toyopuc.MinimalRead
• examples/PlcComm.Toyopuc.HighLevelSample
• examples/PlcComm.Toyopuc.SoakMonitor

Maintainer-only notes and retained evidence live under internal_docs/.

Common User Tasks

• read or write one device: ReadAsync, WriteAsync
• read several devices together: ReadManyAsync, ReadNamedAsync
• read 32-bit integers or float32 values: ReadDWordsSingleRequestAsync, ReadTypedAsync
• change one flag bit inside a word: WriteBitInWordAsync
• read contiguous word blocks: ReadWordsSingleRequestAsync, ReadDWordsSingleRequestAsync
• read large contiguous ranges explicitly: ReadWordsChunkedAsync, ReadDWordsChunkedAsync
• persist FR data: ReadFrAsync, WriteFrAsync, CommitFrAsync
• poll a small watch list repeatedly: PollAsync

Development and CI

Run local CI:

run_ci.bat

Run the release-style check including docs:

release_check.bat

Pack the NuGet package locally:

dotnet pack src\Toyopuc\PlcComm.Toyopuc.csproj -c Release

License

Distributed under the MIT License.
