Open source Seismic Data Sonification package
All the files you can want for is here, including:
- midi file (.mid)
- audio file (.wav)
- plots (event location, seismogram, spectrogram, phase arrivals, score)
- metadata (.csv and .parquet)
=========================================================================
seismic2midi is an open source python package that offers Seismological Data Sonification for a given eventid. Phase arrivals of a given event at a given station’s channel component known as a trace: is decomposed into time, slowness, wave type and amplitude to be mapped as ticks, duration, note number and velocity respectively in the music domain. Geospatial location of the event’s hypocenter (lat/lon/depth) is transformed into spherical coordinate (r, θ, φ) for spatial projection to a given room geometry as an object.
seismic2midi blends seismology and music domain knowledge into a CS pipeline that’s accessible and informative.
If you incorporate it in any occasion, cite as:
Jeremy Leung (2025). seismic2midi (https://github.com/defectedunit/seismic2midi), Seismic Data Sonification package.
Simply by providing an eventid of a seismic event, sesimic2midi can spit out visual, midi and audio representations of the event. Data are stored at export/seismic and export/music for visualization and sonification correspondingly, with various variables to parse in.
.. Note:: To find Earthquake events, you can use the IRIS FDSN client. See https://docs.obspy.org/packages/autogen/obspy.clients.fdsn.client.Client.html#obspy.clients.fdsn.client.Client.get_events
Or Here for laypeople query: https://earthquake.usgs.gov/earthquakes/browse/significant.php?year=2011
For API, you will have to these install dependencies:
# !pip install cartopy
# !pip install obspy
# import cartopy.crs as ccrs
# import obspy
# from obspy import UTCDateTime
This code will return all the events with a magnitude of 7 or higher.
# event_list = client.get_events(minmagnitude=7.0)
event_list
This code will return all the events with a magnitude of 7 or higher during 2024, and .plot() will visualize their locations on a map with robbinson projection.
# event_list = client.get_events(minmagnitude=7.0, starttime=UTCDateTime("2024-01-01"),endtime=UTCDateTime("2025-01-01"))
# event_list.plot()
.. Event and trace variables::
client: default IRIS, for the list of available clients, see https://docs.obspy.org/packages/obspy.clients.fdsn.html
network, station, location, channel: default: 'IU', 'ANMO', '00', 'BHZ' they are for specifying a specific trace's station's channel see https://docs.obspy.org/packages/autogen/obspy.clients.fdsn.client.Client.html#obspy.clients.fdsn.client.Client.get_waveforms
event_summary (bool): retruns a dataframe and stored as ./exports/seismic/event_summary.parquet
.. Seismic variables::
model: default TauPyModel(model="iasp91"), see https://docs.obspy.org/packages/obspy.taup.html
location_plot (bool): default False. Retruns a location plot and stored as ./exports/seismic/f'{filename}_location_plot.png'
seismogram (bool): retruns a time series plot and stored as ./exports/seismic/f'{filename}_seismogram.png
spectrogram (bool): retruns a spectrogram and stored as ./exports/seismic/f'{filename}_spectrogram.png'
model: default TauPyModel(model="iasp91"), see https://docs.obspy.org/packages/obspy.taup.html
Note on arrvial: Phase arrivals are calculated using the TauPy model, around 20-40 arrivals per event.
arrival_rayplot (bool): default False. Retruns a rayplot and stored as ./exports/seismic/f'{filename}_arrival_rayplot.png'
.. Music variables::
fundamental: defualt "C4", by specifying the f0 you can shift the note numbers of the event, essentially a "transpose" slider
tempo_bpm: default 120 Beats Per Minute. See https://en.wikipedia.org/wiki/Beats_per_minute
sperical_coordinates: Retruns a dataframe and stored as ./exports/music/eventid_sperical_coordinates.parquet
midifile (bool): default True. Returns a MIDI file and stored as ./exports/music/f'{filename}_music/.mid'
score (bool): default True. Returns a score and stored as ./exports/music/f'{filename}_score/.png'
audiofile (bool): default False. A preview is provided but you are engouraged to use the midi file in your DAW. Returns a audio file and stored as ./exports/music/f'{filename}_music/.wav'
.. filename::
Default filename = f'{eventid}_{network}_{station}_{channel}'. Feel free to modify as you see fit.
©️ Jeremy Leung (info.sostenuto@gmail.com, IG, Github: @defectedunit)
:license: GNU Lesser General Public License, Version 3 (https://www.gnu.org/copyleft/lesser.html)
