Gear80

Gear80 is a 80% keyboard based on the rp2040.

• gear80_wkl_Aluminum (CNC, Bead blasting-100 mesh + Anodizing-Black-Matte)

• gear80_wkl (sla print)

• Gear80-A_1.0mm (sla print)

Layout

• gear80 hotswap, solder

• gear80-a solder



There is also a keyboard plate.
Keyboard case corresponding to this layout.

PCB

It may differ from the sample photo and file.

More pcb

This pcb was made by jlcpcb.(list of pcb parts main, daughterboard)

This pcb prepared the vial as firmware

typing sound

Gear80 / Aluminum / HMX Hyacinth v2u / PC Plate / ABS / Full foam


Gear80 / Aluminum / HMX Garnet / PC Plate / ABS / no foam


Gear80 Lite / Bsun RAW / PC Plate / ABS / Full foam


Gear80-A / sla / HMX Cheese / PC Plate / PBT / Full foam

Reference

• Gear60
