ESP32 + PlayStation Portable Integration

Plug an ESP32 into a PSP (all models except PSP Go) via the remote port’s UART TX/RX (~2.5 V logic). Originally for remotes and GPS units, this port works great with microcontrollers when using a level shifter like MAX3232.

This allows for homebrew development, GPS integration, debug consoles, or even hardware extensions like LoRa, displays, and remote control systems.

---

Electrical Notes & UART Safety

• PSP remote port uses UART4, which outputs ~2.5 V logic on PSP‑1000 and ~1.9 V on PSP‑2000/3000.
• Do not connect directly to 3.3 V or 5 V UARTs. Use a MAX3232 to convert safely.
• The port is only powered when headphones are plugged in.
• Power pinout on the remote plug varies by model. Typical setup:

Remote Pin	Signal	Function
Pin 1	TX	PSP UART TX
Pin 2	RX	PSP UART RX
Pin 3	GND	Ground
Pin 4–6	—	Unused or audio

---

Wiring Tips

• Use a MAX3232, not MAX232 (which is 5 V).
• MAX3232 modules typically need 5 × 0.1 μF capacitors.
• Use T2IN/T2OUT and R2IN/R2OUT if using ESP32 UART2.
• Connect GND between PSP, MAX3232, and ESP32.
• Some GPS modules (like the Sony PSP-290) can plug directly into the port.
• Homebrew tools (like PSPlink) output UART debug info on this port.

---

Hardware Visualization

Here are some examples of key components:

1. ESP32 development board – generic dev kit
2. Annotated ESP32 board – showing USB port and labels
3. ESP32 DevKitC clone – breadboard-friendly form
4. MAX3232 level-shifter modules – UART level conversion

---

Hardware Options

Module	Purpose
ESP8266 / ESP32‑S3	Wi‑Fi reconnaissance, de-auth, Bluetooth, captive portals
CC1101 / NRF24L01+ / PN532	RF (sub‑GHz), NFC, badge replay cloning
CH340 / FTDI	USB‑serial console
NEO‑6M GPS	Geolocation logging for Wi‑Fi surveys
Digispark / STM32 / ESP32‑S2 HID	USB HID / BadUSB payload delivery
Teensy + Audio Shield / STM32	MIDI/noise glitch synthesis via UART
SX1276 LoRa	Long-range mesh networking
ePaper / OLED Display	Stealth badge or status display
Custom SD/Flash Adapter	Storage for payloads, OS images
Internal USB OTG Mods	Enables PSP as USB host
MAX3232 Level Shifter	Converts between 3.3 V/5 V and 2.5 V UART safely
AMS1117 3.3 V Regulator	Powers ESP32, LoRa, GPS modules

---

ESP32 UART Integration Example

Enable UART2 on the ESP32 to talk to the PSP:

#define RXD2 16  // Connect to PSP TX (via MAX3232)
#define TXD2 17  // Connect to PSP RX (via MAX3232)

void setup() {
  Serial.begin(115200);
  Serial2.begin(9600, SERIAL_8N1, RXD2, TXD2);
}

void loop() {
  if (Serial2.available()) {
    Serial.write(Serial2.read());
  }
}

Alternatively:

HardwareSerial gpsSerial(2);
gpsSerial.begin(9600, SERIAL_8N1, RX_GPIO, TX_GPIO);

This enables UART communication on custom pins and is compatible with many ESP32 boards.

---

Example Use Cases

• Wi‑Fi/Bluetooth serial console
• GPS-tagged Wi‑Fi surveys or wardriving
• LoRa mesh node with display feedback
• USB HID or BadUSB payload delivery (via OTG mod)
• Stealth badge/status interface (OLED/ePaper)
• On-device payload or OS image storage
• Complete media/network add-on inside PSP shell
• Debugging or serial console via PSPlink or custom homebrew
• Emulated remote commands sent to PSP via serial

---
