ACR Standard

ACR: Agentic Control at Runtime

The control plane your autonomous AI agents need before you let them touch production.

📖 Docs · 🚀 Quickstart · 🏛️ For Executives · ⚙️ For Engineers · 🛡️ Threat Model · 📋 Adopt ACR

---

🎯 Pick Your Path

You are a...	Start here
🏛️ CISO, CRO, GRC lead, board member — I need to understand the risk and the answer	For Security & Risk Executives ↓
⚙️ Engineer, SRE, security architect — I need to read the code and run the thing	For Engineers ↓

---

🏛️ For Security & Risk Executives

The problem in one sentence

You are about to give software the authority to act on behalf of your business, and your existing AI governance program stops at the moment that software goes into production.

Traditional AI governance — model cards, pre-deployment reviews, NIST AI RMF documentation, ISO 42001 paperwork — happens before an AI system runs. It produces binders, not brakes. The moment an autonomous agent starts accessing customer data, calling APIs, issuing refunds, or filing tickets on your behalf, your design-time controls have nothing to enforce against.

That gap is where the risk lives: a perfectly compliant agent on day one can drift, be manipulated, or simply behave unexpectedly on day ninety — and there is nothing in your stack to notice, throttle, or stop it.

What ACR is, in plain terms

ACR is the seatbelt, airbag, ABS and crumple zone for autonomous AI. It is a runtime control plane that sits between your AI agents and the systems they touch, and it enforces your governance policies on every single action the agent attempts — before that action ever leaves the building.

It does not replace your AI governance program. It is the part of the program that executes.

What ACR gives you

Outcome	What it means in practice
🛑 A real "off switch."	A single command, kept on a separate system from the agent itself, instantly disables an agent globally. Even a compromised control plane cannot silently re-enable it.
🚦 Graduated containment, not just on/off.	If an agent starts behaving abnormally, the system automatically throttles it, then restricts its tools, then escalates everything to a human, and only kills it as a last resort. Four tiers, no operator paged at 3am for the small stuff.
👁️ A complete, signed audit trail of every decision.	Every action an agent attempted, every policy that fired, every approval, every override — all hashed and exportable as a tamper-evident evidence bundle for auditors and incident response.
🧑‍⚖️ Human-in-the-loop, where it matters.	High-risk actions (refunds above a threshold, schema changes, cross-tenant access) automatically pause and route to a named human approver with an SLA. If the human doesn't respond in time, the action auto-denies.
📉 Drift detection on agent behavior, not just model accuracy.	The system continuously baselines what "normal" looks like for each agent and raises a score when an agent starts using new tools, denying more often, or behaving more erratically than its baseline allows.
📜 Compliance you can actually evidence.	Pre-built mappings to NIST AI RMF, ISO/IEC 42001, and SOC 2, with the audit artifacts to back them up. Auditors get a download, not a meeting.

The six pillars (the executive version)

ACR enforces six categories of control on every agent action:

#	Pillar	What it answers
1️⃣	Identity & Purpose Binding	"Is this really our agent, and is it doing what we hired it to do?"
2️⃣	Behavioral Policy Enforcement	"Is this specific action allowed by our policy, right now?"
3️⃣	Autonomy Drift Detection	"Is this agent behaving the way it did last week?"
4️⃣	Execution Observability	"Can we prove what happened, to whom, when, and why?"
5️⃣	Self-Healing Containment	"If it starts misbehaving, does it stop itself before we have to?"
6️⃣	Human Authority	"When the stakes are high, does a human still get the final say?"

Why this matters now

Three forces are converging:

1. Regulators are catching up. The EU AI Act, NIST AI RMF, and emerging US state laws all expect operational AI controls, not just paperwork.
2. Insurers are pricing AI risk. Carriers are starting to ask whether you have runtime governance — not whether you have a model card.
3. The agents are getting more autonomous. Tool use, multi-step planning, and agent-to-agent delegation mean the blast radius of a single bad decision is growing fast.

Doing nothing is itself a decision. ACR gives you a defensible, standards-aligned, open-source answer.

How to evaluate ACR in 30 minutes

1. Read this section. ✅ You are most of the way there.
2. Skim the Six Pillars overview — one paragraph per pillar.
3. Look at the NIST AI RMF mapping to see how it lines up with the framework you are already being measured against.
4. Hand the engineering section below to your security architect. They will be able to tell you in an afternoon whether this fits your stack.

💡 Bottom line for the board: ACR is the difference between "we have an AI policy" and "we can prove our AI followed the policy on every one of last quarter's 14 million decisions, and we stopped it the three times it tried not to."

---

⚙️ For Engineers

TL;DR

ACR is a policy-enforcing gateway for AI agents. Every action an agent wants to take goes through POST /acr/evaluate and gets a allow | deny | escalate decision in <200ms. It's a single FastAPI service backed by Postgres + Redis + OPA, with a separate kill-switch sidecar, deployable on Kubernetes or docker compose up.

🚀 Quickstart (60 seconds)

git clone https://github.com/AdamDiStefanoAI/acr-framework.git
cd acr-framework/implementations/acr-control-plane
cp .env.example .env
docker compose up --build

Migrations run automatically on startup (one-shot acr-migrate service). When the gateway is healthy:

curl http://localhost:8000/acr/health
# → {"status":"healthy","version":"1.0","env":"development"}

# Open the operator console
open http://localhost:8000/console
#   Operator API key:    dev-operator-key
#   Kill-switch secret:  killswitch_dev_secret_change_me

That's it. You now have a working six-pillar control plane on your laptop.

The hot path

sequenceDiagram
    autonumber
    participant A as Agent (JWT)
    participant G as ACR Gateway
    participant R as Redis
    participant DB as Postgres
    participant O as OPA
    participant K as Kill-switch (sidecar)
    participant H as Human approver

    A->>G: POST /acr/evaluate {action, params}
    G->>G: [0] JWT subject == agent_id
    G->>R: [1] is_killed?  (~0.5ms)
    G->>R: [1b] containment tier?
    G->>DB: [2] agent active + lifecycle ok
    G->>R: [3] rate-limit bucket
    G->>O: [4] Rego evaluate
    O-->>G: allow / deny / escalate
    G->>G: [5] PII filter on params
    alt escalate
        G->>DB: create approval request
        G->>H: signed webhook
        G-->>A: 202 APPROVAL_PENDING
    else allow / deny
        G-->>A: 200 / 403
    end
    Note over G,DB: BackgroundTasks (non-blocking):<br/>persist telemetry → drift sample →<br/>recompute drift score every N calls
    Note over K: Kill writes go through<br/>independent service.<br/>Reads are Redis-direct.

Loading

Latency budget: ~5ms identity, ~10ms rate limit, ~20–50ms OPA, <5ms PII filter. Total p95 target: <200ms, telemetry/drift never blocks the response.

Architecture at a glance

                ┌─────────────────────────────────────────────────────────┐
                │                  ACR Control Plane                      │
                │                                                         │
   Agent ──JWT──▶│  FastAPI gateway  ──▶  OPA (Rego policies)             │
                │        │                                                │
                │        ├──▶ Postgres (agents, telemetry, approvals,     │
                │        │              drift baselines, policy releases) │
                │        │                                                │
                │        ├──▶ Redis (kill switch, rate limits, drift cache)│
                │        │                                                │
                │        └──▶ Background tasks (telemetry, drift, sweeps) │
                │                                                         │
                └─────────────────────────────────────────────────────────┘
                           │                              │
                           ▼                              ▼
                ┌──────────────────┐          ┌──────────────────────┐
                │ Kill-switch SVC  │          │   Human approvers    │
                │ (independent,    │          │ (HMAC-signed webhook │
                │  separate auth)  │          │  + operator console) │
                └──────────────────┘          └──────────────────────┘

The six pillars (the engineering version)

#	Pillar	Module	Backed by
1	Identity & Purpose Binding	pillar1_identity/	JWT (HS256/RS256/ES256, alg-pinned), Postgres agents table, lifecycle state machine (draft → active → deprecated → retired), lineage chain, capability tags, heartbeat sweep loop
2	Behavioral Policy Enforcement	pillar2_policy/	OPA via pooled httpx.AsyncClient, exponential-backoff retry, aiobreaker circuit breaker (5 fails / 60s → fail-secure deny). Policies authored in Rego with a draft → release → activate Studio lifecycle.
3	Autonomy Drift Detection	pillar3_drift/	Four signals — denial rate (0.35), call frequency (0.25), error rate (0.20), action diversity / Shannon entropy (0.20). Two-tier baselines: live ungoverned + versioned governed (candidate → approved → active) with dual-approval.
4	Execution Observability	pillar4_observability/	Structured ACRTelemetryEvent per request, correlation-ID indexed, OTLP + Prometheus exporters, SHA256-signed evidence bundles via /acr/evidence/{correlation_id}.
5	Self-Healing Containment	pillar5_containment/	Four graduated tiers — Throttle (0.60) → Restrict (0.75) → Isolate (0.90) → Kill (0.95). Kill writes go through an independent sidecar with its own KILLSWITCH_SECRET so a compromised gateway cannot silently re-enable agents.
6	Human Authority	pillar6_authority/	Persisted approval requests with configurable SLA (default 240m), background expiry loop, HMAC-SHA256-signed webhooks with idempotency keys, break-glass override (security_admin only, mandatory reason, WARN-logged).

Stack & ops posture

• Language: Python 3.11+, FastAPI, async SQLAlchemy 2 + asyncpg, Pydantic v2
• Stores: PostgreSQL (monthly partitioned telemetry_events and drift_metrics, 90-day retention sweep), Redis 7
• Policy engine: Open Policy Agent (Rego), with a draft/release/activate Policy Studio
• Auth: JWT for agents (alg allowlist), API keys and OIDC for operators, four RBAC roles (agent_admin, security_admin, approver, auditor)
• Observability: structlog JSON logs, OpenTelemetry OTLP traces + metrics, /acr/metrics Prometheus endpoint, SHA256-signed evidence bundles
• Deployment: docker compose for local, Kustomize for Kubernetes (HPAs, PDBs, NetworkPolicies, RBAC, init container that runs alembic upgrade head automatically)
• CI: GitHub Actions with lint, test, pip-audit security scanning

Design choices that matter

• Fail-secure everywhere. OPA down → deny. Redis down → deny. Unexpected exception → deny. Never silently allow.
• The kill switch is a separate process. Reads are Redis-direct for the hot path; writes go through an independent service with its own secret. A compromised gateway cannot un-kill an agent.
• Hot path is non-blocking. Telemetry persistence, drift sampling, and drift score recomputation are all BackgroundTasks. The 200ms latency budget covers only the decision, not the bookkeeping.
• Policy is code, not config. All allow/deny/escalate logic is Rego, versioned and shipped through the Policy Studio's release lifecycle. No if statement in Python policy decisions.
• Drift baselines have governance. Without it, a slowly-misbehaving agent could simply re-baseline itself into "normal." Governed baselines require proposal → approval → activation by separate operators.
• Migrations are automatic. Both K8s and docker compose run alembic upgrade head before the gateway starts. You cannot forget to migrate.
• Weak secrets are rejected at startup. Production environments refuse to boot with default JWT keys, weak kill-switch secrets, or missing executor HMAC keys.

The agent registry (Pillar 1, expanded)

The registry is more than a key-value store — it carries the metadata other pillars need to make smart decisions:

Field	Why it exists
agent_id, owner, purpose, risk_tier	Identity and accountability
version	Audit trail of which version of an agent did what
parent_agent_id	Lineage for orchestrator → subagent relationships (non-FK so retirement preserves history)
capabilities[]	Declared skills, distinct from the tool allowlist — used by /acr/agents/discover
lifecycle_state	draft → active → deprecated → retired state machine, gates the evaluate hot path
health_status + last_heartbeat_at	Stale agents auto-downgrade to unhealthy via the sweep loop
allowed_tools[] / forbidden_tools[]	Authoritative tool boundaries enforced by Rego
boundaries	Rate, spend, region, and credential rotation limits

API surface (selected)

POST   /acr/evaluate                          # the hot path
POST   /acr/agents                            # register
GET    /acr/agents/discover?capability=...    # discovery
POST   /acr/agents/{id}/lifecycle             # state transitions
POST   /acr/agents/{id}/heartbeat             # health
GET    /acr/agents/{id}/lineage               # ancestor chain + children
POST   /acr/agents/{id}/token                 # issue short-lived JWT

GET    /acr/drift/{id}                        # current drift score
POST   /acr/drift/{id}/baseline/propose       # governed baseline workflow
POST   /acr/drift/{id}/baseline/{ver}/approve
POST   /acr/drift/{id}/baseline/{ver}/activate

GET    /acr/events/{correlation_id}           # decision chain replay
GET    /acr/evidence/{correlation_id}         # signed evidence bundle (SHA256)

POST   /acr/approvals/{id}/approve            # human authority
POST   /acr/approvals/{id}/override           # break-glass (WARN-logged)

GET    /acr/health  /acr/live  /acr/ready     # k8s probes
GET    /acr/metrics                           # Prometheus text

Full OpenAPI is served at /docs and /redoc (operator-authenticated outside development).

Repo layout

acr-framework/
├── docs/                            ← framework spec (the "why")
├── implementations/
│   └── acr-control-plane/           ← runnable reference implementation
│       ├── src/acr/
│       │   ├── pillar1_identity/    ← registry, lifecycle, lineage, JWT
│       │   ├── pillar2_policy/      ← OPA client, circuit breaker, output filter
│       │   ├── pillar3_drift/       ← signals, baselines, governance
│       │   ├── pillar4_observability/ ← telemetry, OTLP, evidence bundles
│       │   ├── pillar5_containment/ ← graduated tiers, kill switch
│       │   ├── pillar6_authority/   ← approvals, webhooks, override
│       │   ├── policy_studio/       ← draft → release → activate lifecycle
│       │   ├── gateway/             ← FastAPI router, middleware, executor
│       │   ├── operator_console/    ← read-only web UI
│       │   └── db/migrations/       ← Alembic (head: 0012)
│       ├── policies/                ← Rego policies + tests
│       ├── deploy/k8s/base/         ← Kustomize manifests
│       ├── tests/                   ← 160+ unit + integration tests
│       ├── docker-compose.yml
│       └── Dockerfile{,.killswitch}
└── README.md                         ← you are here

Where to look first if you're reading the code

1. src/acr/main.py — application wiring, lifespan, background loops
2. src/acr/gateway/router.py — the /acr/evaluate hot path
3. src/acr/pillar2_policy/engine.py — the OPA client with retry + circuit breaker
4. src/acr/pillar5_containment/graduated.py — the four-tier containment ladder
5. policies/ — the Rego policies that actually make the allow/deny calls

Compliance mappings

Standard	Mapping
🇺🇸 NIST AI RMF	docs/compliance/acr-nist-ai-rmf-mapping.md
🌍 ISO/IEC 42001	docs/compliance/
🔒 SOC 2	docs/compliance/
🛡️ Threat model	docs/security/acr-strike-threat-model.md

Project status

• ✅ Six pillars implemented and tested
• ✅ Production-grade Kubernetes manifests
• ✅ Automated migrations (no manual alembic upgrade head)
• ✅ Compliance mappings for NIST AI RMF, ISO 42001, SOC 2
• ✅ 160+ unit tests, evidence-bundle integration tests
• 📋 Roadmap · Changelog · Adoption guide

Contributing

We welcome PRs, issues, and threat-model discussions. See CONTRIBUTING.md, GOVERNANCE.md, and CODE_OF_CONDUCT.md. Security issues: SECURITY.md.

---

Like OWASP for AppSec. Like MITRE ATT&CK for threats.

ACR is the reference architecture for runtime AI governance.
