MusicPi

MusicPi is a modular, extensible, and hackable music/media Python system for Raspberry Pi, designed for physical controls, OLED display, and integration with custom hardware (like Pico microcontrollers). It’s perfect for building your own jukebox, media center, or interactive music player! The system uses different programs to support easy setup and bug tracking.

I encourage you to edit the code to suit your needs. Further explanation is provided here, in the MusicPi Instructable.

Features

MusicPi incorporates many features to make for the best user experience, simple interaction with an OLED display six buttons, and a potentiometer.

• Physical Controls: Use buttons, rotary encoders, and potentiometers for playback, navigation, and volume/tone control.
• OLED Display: Real-time menu, notifications, and playback info on an OLED screen.
• MPV Integration: Robust playback via MPV, supporting local files and streams.
• Dynamic Menus: Auto-generated menus from a specified music folder
• Pico Microcontroller Support: CircuitPython/MicroPython code for sending keypresses and analog data to the Pi.
• Logging: All actions and errors are logged for easy debugging.
• Modular Design: Easy to extend with new controls, displays, or features.

Programs Structure

These small descriptions only provide an overview of the actual things the programs do and how they do them. To get a real feel for it, look at the code.

background.py           # Manages system state, power, and screen
evdevlib.py             # Helps with listening for key events from input devices
generate_albums_json.py # Scans music folders and generates menu JSON for music_system.py
handle_volume.py        # Handles volume commands via serial and adjust volume accordingly
music_player.py         # MPV-based playback control
music_system.py         # Main system logic and menu navigation
OLED.py                 # OLED display library
OLED/                   # OLED library, examples, and assets
Pico/                   # Microcontroller code and examples

Setup & Installation

1. Dependencies

The free programs listed below are all necessary unless you edit the MusicPi system.

• Python for running the programs
• MPV for playing media
• socat for sending ipc commands to mpv processes
• Pillow for image handling
• Mutagen for MP3 metadata
• evdev for input device handling
• Waveshare OLED Python Library for control of the OLED display

Here are some helpful references

• MPV JSON IPC
• CircuitPython HID
• gpiozero

2. Parts Suggestions

These are the parts I used, the bare minimum needed to run the MusicPi system. The full guide to replicating my build is detailed on the instructable linked to above. Any deviation from them will require reprogramming and optimization of the MusicPi code for your hardware (extra fun I think).

• Raspberry Pi 4 (any should work though)
• Raspberry Pi Pico (again, any should work, but I would suggest the Pico H as it's slightly less expensive then the other variants and comes with pre-soldered headers)
• Waveshare General 0.91" OLED Display Module
• USB Data Cable
• Breadboard
• Breadboard Jumper Wires
• Push buttons

3. Hardware Connections

Place the pico to the breadboard. Connect the buttons to the GPIO pins as detailed in the MusicPi/Pico/main.py program, or switch things up and customize the code to register your different button connections. Connect the Waveshare General 0.91" OLED Display Module to the Raspberry Pi as shown below (the MusicPi system does not use the originial waveshare OLED library so connect the wires my way or it won't work.) Plug the USB data cable into the Pico on one end and a computer on the other.

4. Software Setup

• Install the dependencies with the following commands:

sudo apt-get update
sudo apt-get install python3-pip python3-pil python3-numpy mpv socat python3-mutagen python3-evdev python3-gpiozero python3-pil

• Download the MusicPi folder into the root of a prepared Raspberry Pi OS computer
• Flash the Pico with the latest Circuit Python UF2 (https://learn.adafruit.com/getting-started-with-raspberry-pi-pico-circuitpython/circuitpython), and then copy the main.py program over to the Pico's root folder.
• Setup MusicPi/background.py to run on boot of the Raspberry Pi (you can use Botspot's Autostar https://github.com/Botspot/autostar)
• Fill ~/Music with media and music for the system
• Reboot

5. Using Different Hardware and Techniques

• OLED You can swap out the OLED I used for basically any other one out there. All you have to do is pop the new OLED's library into the MusicPi folder, replace the OLED lib calls in OLED.py with some that will properly talk to your OLED lib, and connect your OLED to the pi as specified in its documentation.
• Pico There is a lot of opportunity for customization with how the MusicPi system takes input from users. You could replace the pico with a website hosting program that could give keypresses and volume commands to the system in the same fashion the pico currently can. You'd have to tell evdevlib.py to listen for keypresses from a specific program and handle_volume.py to accept volume commands through some sort of connection to the same program.

Using MusicPi

1. Controls

These are the keypresses that music_system.py responds to. See Pico/keys_used.txt for key mappings:

Button	Key Sent	Function
Backward	F1	Previous track/menu up
Play/Pause	F2	Play/Pause/Enter
Forward	F4	Next track/menu down
Mode	F6	Main menu
Display	F7	Power off
Stop	F8	Stop playback/back
Power	F9	Toggle system prog on/off
BCD	F12	Toggle screen

2. OLED Display

• Menus, notifications, and playback info are shown using OLED.py.
• Customizable with Pillow fonts and images.
• Example usage in OLED/example/waveshare_example.py.

3. Changing Settings

The settings.json file, located in the MusicPi root directory, allows you to customize a few key settings:

• mediaDir: Specifies the directory where MusicPi will look for your media files.
• picoPort: The system port corresponding to your Raspberry Pi Pico device.
• eventDevice: The event device file associated with your Pico for input events.

How to find your Pico port and event device

To locate the correct picoPort and eventDevice on your computer:

1. Connect your Raspberry Pi Pico.
2. Open Thonny IDE.
3. In Thonny, check the interpreter options; it should display your Pico and its associated port (e.g., /dev/ttyACM0).
4. For the eventDevice, check the /dev/input/ directory for event devices created by the Pico (e.g., /dev/input/event4).

Example settings.json:

{
  "mediaDir": "/home/me/Music",
  "picoPort": "/dev/ttyACM0",
  "eventDevice": "/dev/input/event4"
}

4. Adding Media

You can add nearly any type of media to the media folder for the MusicPi system to play.

Supported Media Types

• Audio and video files supported by MPV.
• .m3u playlist files for streaming content (e.g., YouTube URLs).

Using .m3u Files for Streaming

To stream media from online sources:

1. Create a text file with a .m3u extension.
2. Paste the direct media link (e.g., a YouTube URL) into the file.
3. Place the .m3u file in your media directory.

MPV will handle the streaming and playback seamlessly.

Folder and File Ordering

MusicPi supports ordered folder structures. You can name your folders and files with numeric prefixes to control the display and playback order.

For example:

/media
├── 01. Folder One
│   ├── 01. Song A.mp3
│   └── 02. Song B.mp3
├── 02. Folder Two
└── 03. MyPlaylist.m3u

These numeric prefixes determine the playback order. MusicPi will strip the numbers when displaying names on the OLED screen, showing clean, user-friendly titles like:

• Folder One
• Folder Two
• MyPlaylist

Extending MusicPi

Please feel free to suggest and push improvements to the repo. Here are a few things that could be added:

• Add new menu actions in generate_albums_json.py.
• Add a web socket program to host a website and push keypresses inside the system based on buttons pressed on the website

Debugging

If something isn’t working as expected, don’t worry — most issues are easy to track down. Start by checking log output (musicpilog.log) and using the tips below. You can always post an issue to the repo if the below doesn't help.

1. Startup Timing

• background.py runs at system startup, but it’s best to wait a few seconds after the desktop GUI finishes loading before interacting with the device.
• Pressing the system program toggle (F9) too early may prevent the system from initializing correctly.
• If nothing happens or the display remains blank, try rebooting the Raspberry Pi and waiting a moment before pressing any controls.

2. Menu or JSON Issues

• If music_system.py crashes, menus are missing, or playback options don’t appear, try deleting the menus.json file.
• Then regenerate it by running generate_albums_json.py again.

3. General Troubleshooting

• Make sure your media files are placed correctly in the directory specified in settings.json.
• Verify that your Pico is detected (check system device list or /dev/ttyACM*) and that the correct eventDevice is set.

Credits

• ComputerL
• VS Code
• Waveshare for OLED libraries
• Adafruit for HID libraries
• VS Code
• ChatGPT
• Github Copilot helped mainly with evdevlib.py, generate_albums_json.py, and documentation

License

This project is licensed under the MIT License.
© 2025 ComputerL (@1ComputerL). See the LICENSE file for details.
